General Information & Highlights

Premium Quality on Every Surface, Creative Solutions for Every Industry

Whether it’s for promotion, advertising, furniture, decoration, or glass — our technology delivers vibrant, sharp, and high-resolution prints on materials of various thicknesses and textures. With 2400 dpi resolution and 5 picoliter droplet size, your colors look brighter and your details sharper than ever.

Thanks to its advanced UV Flatbed technology and powerful vacuum system, the material stays firmly in place during printing. This ensures flawless results, even on uneven or textured surfaces.

From glass to wood, metal to plastic — create stunning prints on virtually any surface. Stand out and stay ahead with the KCXL UV Printing Machine!

Specifications

Color Scale

CMYK + Lc + Lm + W + V

Drop Volume

5 Pl.

Drying System

LED UV

Flat-Bed Size

2500mmx1250mm / 3050mmx2050mm

Ink Types

LED UV

Machine Size 2512

2200mm x 5220mm x 1530mm

Machine Size 3020

3000mm x 5800mm x 1530mm

Machine Weight

1370 - 2500 kg.

Maximum thickness

100 mm

Power Requirements

230v (+/-) 10% / 40A / 50HZ / 60HZ

Print Heads

RICOH GEN6

Print Resolution

2400 dpi

Print Speed Up to

90 m2/h

Printhead Quantity

16 (Max.)

RIP Software

Photo Print - Caldera (Opt.)
